| No. | Parameter / Component | Unit | Specification Details |
|---|---|---|---|
| 1 | Maximum drilling diameter | mm | 500-1800 |
| 2 | Maximum drilling depth | m | 30 |
| 3 | Safe drilling operation range (from the rotary center) | mm | 3500 |
| 4 | Drilling rig size under working condition (length * width * height) | mm | 6700 * 4000 * 13500 |
| 5 | Drilling rig size in transportation state (length * width * height) | mm | 11500 * 2900 * 3650 |
| 6 | Operating weight (including drilling tool under standard configuration) | t | 29.5 |
| 7 | Motor Brand & Model (Cummins Engine) | / | Cummins QSB7 (Emission Stage: 3 Stages) |
| 8 | Engine rated power/speed | kW | 135 |
| 9 | Hydraulic system - Maximum working pressure of main pump | MPa | 30 |
| 10 | Power head rated output torque | kN·m | 130 |
| 11 | Power head operating speed | r/min | 8-48 |
| 12 | Feed cylinder - Maximum pressurization / Maximum lifting force | kN | 120 / 120 |
| 13 | Feed cylinder pressurization stroke | mm | 2500 |
| 14 | Main winch lifting force / Maximum single rope speed | kN | m/min | 130 | 60 |
| 15 | Diameter of main winch wire rope | mm | 24 |
| 16 | Auxiliary winch lifting force / Maximum single rope speed | kN | m/min | 30 | 55 |
| 17 | Diameter of auxiliary winch wire rope | mm | 12 |
| 18 | Drill mast inclination (Left/Right) & Mast rake | ° | ±4 | ±4 |
| 19 | Turntable rotation angle | ° | 360 |
| 20 | Maximum traveling speed & Maximum gradient | km/h | % | 5 | 30 |
| 21 | Chassis track width & Total track width | mm | 600 | 2900 |
| 22 | Chassis wheel distance | mm | 4000 |
| 23 | Drill pipe specification | / | 360 Machine lock |
